Perfume wrapping  machine

Is your company looking for reliable and affordable perfume packaging systems and supplies? We are professioal manufacturer from China,we have various machines for your various packaging needs.Choose from Automatic cellophane wrapping machine, cartoning machine and semi-automatic cellophane wrapping machine.They will help you reduce labor, improve production efficiency and improve product quality.
We have several models of machines. You need to determine your packaging size first, and then determine the machine model based on the product size and specific needs.And we also support customization,just send your inquiry to me!

点烫效果2
点烫效果32
平烫效果12

Application and Features:
1. This machine is widely used for automatic packaging of large, medium and small box products in single or collective packages. It adopts PLC human-machine interface control, and the main drive is completed by servo control. The servo motor control the film feeding, and the film size can be adjusted at will; the machine platform and the contact parts of the packaged objects are made of stainless steel materials, which meet the hygiene standards. Only a small number of parts need to be replaced to package box-shaped items of different specifications (size, height, width).
2. Dual servo drive model, fast speed, good stability; it is an ideal choice for multi-specification and multi-variety three-dimensional packaging.



Model

Voltage

Power

Packaging Speed

Packaging Size

Machine size



360



380V/50HZ



10KW



20-45box/min

L50-280mm

W40-180mm

H20-80mm

L2300mm

W1000mm

H1750mm

Note: 1. Length and thickness cannot be set to upper or lower limits at the same time; 2. Width and thickness cannot be set to upper or lower limits at the same time; 3. Packaging speed is related to the hardness and size of the packaging material;

This machine is widely used in medicine, health care products (condom)), cosmetics, tea, food, cigarette,and playing cards (internal and external package), stationery (such as eraser, signs etc.), various box products in the industries such as electronic cigarette packaging. Automatic damp proof, dustproof, anti fake function, also can improve the packing the grade of products, improve the added value of the products



Characteristic

1, compact and reasonable structure, stable performance, convenient operation and maintenance;

2, using the multi-function digital converter, packing speed can be stepless speed;

3, mould replacement is convenient, flexible, automatic counting;

4, the transmission part is provided with a protection device and fault prompt;

5, no packaging, no film feeding, no waste of packaging materials;

6, can be equipped with photoelectric tracking, code printer, lack box function, automatic film device.



Main technical parameters

Packing speed

30-90box/minute

Packing material

BOPP heat sealing film and tear tape

Max packing film size

300x200/320×260/360×380(mm)

Packing size

L50-320 W20-140 H10-90 (mm)

Equipment size

240750×1600 (mm)

Equipment weight

750kg

power

5kw

voltage

220V/50Hz

This machine requires manual sealing of the first long side,and the fold and other side sealing will complete by machine.It's greatly reduced labor.And it's cheap than automatic machines and easy to change moulds.Very suitable for small business.



Main technical parameters

Packing speed

2-15box/minute

Packing material

BOPP  film and tear tape

Packing size

L50-280 W20-180 H10-80 (mm) Also can customize

Equipment size

200750×1200 (mm)

Equipment weight

150kg

power

5kw

voltage

220V/50Hz
